Material Hoist

Product Detail

Material Hoists are primarily used for the vertical transportation of materials on high-rise construction sites, such as for concrete, rebar, formwork, and large equipment. Their use can improve construction efficiency and shorten project schedules.

Flexible lifting heights - Hoists can be set up at different lifting heights according to actual needs, generally up to 650 feet maximum.

High lifting speeds - Large capacity Material Hoists can reach speeds of up to 180 feet per minute.

Large load capacities - Maximum load capacities can reach up to 4,400 pounds.

Simple and convenient operation - Professional operators can quickly install and utilize them.

Safe and reliable - They are equipped with overload protection, buffer stopping, and other safety features.

Guide rail frame with special treatment and the building surface parallel.

Use a floating leveling mechanism to ensure that the construction elevator is moving along the curve.

When the hanging cage is kept horizontal applicable to cooling tower and curved buildings and other construction projects.

Advantage

• Frequency conversion control, wireless control
• Automatic leveling, safe and reliable
• Convenient installation, disassembly and maintenance

Technical date of Freight Elevator

Remark:

• Recommended cage dimension (L×W×H) (m): 3×1.5×2.2 Cage dimensioncan be made according to requirement of customer.
• Various brand of motor sets available for customer optional.
• Recommended normal speed hoist installation height ≤ 100m.

DXCM Hoist Color Optional
